We offer brand new Konica Minolta 512 printhead (KM512) for HP designjet 9000s,Seiko 64s/100s and other Chinese brand large format printers.14pl or 42pl is avaliable.
Remark: Original
Normal working life:1-2 years.
Parameters:
| Product Name | KM512L | KM512M | KM512S |
| Drive Mode | Piezo Drop-On-Demand | ||
| Nozzle Resolution | 180dpi*2 rows = 360dpi | ||
| Nozzle Number | 256 nozzles*2 rows = 512 | ||
| Nozzle Spacing | 70.5μm =(141um 2 rows) | ||
| Drop Volume | 42pl | 14pl | 4pl |
| Firing Frequency | 7.6kHz | 12.8kHz | 23.0kHz |
| Print Width | 36.1mm | ||
| Dimensions | 67mmW*40mmD*72mmH | ||
| Solvent Ink | OK | OK | OK |
| UV Ink | OK | OK | OK |
| Oil Ink | OK | OK | OK |
| Max. Drops in Greyscale | - | 3 drops | 7 drops |
| With Heater (H) | Available | Available | Available |
| Without Heater (N | Available | Available | N.A. |
